X5 Wired Warehouse Door Chime and Bell Kit – Heavy-Duty Wired Doorbell System for Warehouses, Shops, and Commercial Spaces - With Low-Voltage Original Bell

SKU: MB X5 WWDB

Introducing the X5 Wired Warehouse Doorbell Kit with low-voltage Original Bell, a heavy-duty doorbell system designed for warehouses, shops, loading docks, commercial buildings, and other demanding work environments.

This kit includes a rugged heavy-duty wired warehouse doorbell button, an X5 chime receiver, and a red low-voltage Original Bell. The heavy-duty wired doorbell button connects directly to the X5 chime using the included 50' low-voltage wire. The red low-voltage Original Bell connects to the X5 chime’s 12V DC output using the included 5' wire.

Additional low-voltage wire can be added or spliced into either connection if longer wire runs are needed. The wire run between the heavy-duty wired doorbell button and the X5 chime can be extended up to 250' total. The wire run between the low-voltage Original Bell and the X5 chime can also be extended up to 250' total. Stranded 18AWG low-voltage wire is recommended for extended runs.

Built for reliability and everyday use, the X5 Wired Warehouse Doorbell Kit helps make sure you never miss a visitor, delivery, driver, or customer at an entry door, dock door, service counter, gate, or shop entrance.

Key Features of the X5 Wired Warehouse Doorbell Kit

Heavy-Duty Wired Doorbell Button

This kit includes the X5 Heavy-Duty Wired Button Transmitter, designed for tough warehouse and commercial environments. The button is a normally open momentary contact button that connects directly to the X5 chime using low-voltage wiring.

The kit includes 50' of low-voltage wire for connecting the heavy-duty wired doorbell button to the X5 chime. If a longer distance is needed, additional low-voltage wire can be added or spliced into this button connection. The wire run between the wired doorbell button and the X5 chime can be extended up to 250' total using stranded 18AWG low-voltage wire.

Because this is a wired button, it does not require a battery at the button location and is ideal for permanent installations where a direct wired connection is preferred.

Low-Voltage Original Bell Included

This kit includes Milton’s Bells red low-voltage Original Bell for a louder bell alert. The Original Bell connects to the X5 chime’s 12V DC output and is powered by the chime.

The kit includes 5' of wire for connecting the red low-voltage Original Bell to the X5 chime. If the Original Bell needs to be mounted farther from the chime, additional low-voltage wire can be added or spliced into this bell connection. The wire run between the low-voltage Original Bell and the X5 chime can be extended up to 250' total using stranded 18AWG low-voltage wire.

Expandable Low-Voltage Wiring

The X5 Wired Warehouse Doorbell Kit is designed to give installers flexibility when placing the wired button, chime, and Original Bell.

The included wiring provides 50' between the heavy-duty wired doorbell button and the X5 chime. This button wire run can be extended up to 250' total.

The included wiring also provides 5' between the red low-voltage Original Bell and the X5 chime. This Original Bell wire run can also be extended up to 250' total.

These are separate wire runs. The button-to-chime wire run may be up to 250', and the Original Bell-to-chime wire run may also be up to 250'. Stranded 18AWG low-voltage wire is recommended for extended wiring.

This gives installers flexibility to place the wired button at the entry point and the Original Bell where it can be heard best.

Built for Harsh Conditions

The included wired button is rugged, weather-resistant, and built for outdoor or demanding indoor installations. It is a strong choice for warehouse docks, shop entrances, commercial doors, gates, service areas, and other locations exposed to daily use or changing weather conditions.

Connects Directly to the X5 Chime Receiver

The wired button connects directly to the X5 chime receiver with low-voltage wire. This makes the system a dependable option for locations where you want a hardwired button connection instead of relying only on a wireless button.

One Wired Button per X5 Chime

Each X5 chime receiver can support one wired button connection. This makes the wired kit ideal for a main entrance, dock door, shop door, or other primary access point.

Mix Wired and Wireless Buttons

The X5 system also allows you to add wireless buttons in addition to the wired button. You can use one wired button with the X5 chime and still expand the system with up to 16 additional wireless buttons, giving you flexible coverage for multiple doors, gates, or zones.

Custom Chime Sounds

Choose from 16 different chime sounds on the X5 receiver. This allows you to customize the alert sound and, when using multiple wireless transmitters, assign different sounds to different doors or access points so you know exactly where attention is needed.

Dual 12V DC Outputs for Accessories

The X5 receiver includes two 12V DC outputs for connecting low-voltage accessories such as a strobe light, siren, or Milton’s Bells Original Bell.

In this kit, the included red low-voltage Original Bell connects to one of the X5 chime’s 12V DC outputs and is powered by the chime. The included 5' wire may be extended if needed. The wire run between the low-voltage Original Bell and the X5 chime can be extended up to 250' total using stranded 18AWG low-voltage wire.

These accessory outputs allow the system to provide both audible and visual alerts, which is especially useful in loud warehouses, shops, workshops, loading docks, and commercial environments where a standard doorbell chime may not be enough.

Low-Voltage Accessory Flexibility

Compatible low-voltage accessories can be connected to the X5 receiver to expand the alert system. Add a strobe light for visual alerts, a loud-ringing Original Bell for a classic sound, or a siren for louder notification in noisy work areas.

For larger spaces, accessory wiring can be extended using low-voltage wire so alerts can be placed where they are most useful. When using the included low-voltage Original Bell, the wire run between the Original Bell and the X5 chime can be extended up to 250' total using stranded 18AWG low-voltage wire.

Customizable Sound Options for Your Doorbell Chime

16 Chime Sounds

The X5 chime receiver includes 16 selectable sounds, allowing you to choose the alert tone that works best for your location.

Seasonal Sounds

The X5 also includes seasonal chime sounds, including Halloween and Christmas tones, for businesses that want a more festive alert option during the holidays.

Adjustable Alert Options

The X5 chime provides a clear indoor alert. For louder or more visible notifications, connect compatible low-voltage accessories such as a strobe light, Original Bell, or siren.

Great for Warehouses and Commercial Spaces

The X5 Wired Warehouse Doorbell Kit is ideal for:

Warehouse entry doors

Loading docks

Shop entrances

Commercial service doors

Office-to-shop communication

Customer pickup areas

Gates and access points

Noisy work areas

Large buildings needing accessory alerts

Expandable X5 System

The X5 Wired Warehouse Doorbell Kit gives you a strong wired starting point while still allowing future expansion. Use the wired button for your main door, then add wireless X5 buttons as needed for other doors, docks, gates, or work areas.

Please note: the X5 product line uses its own dedicated radio signal for X5 wireless accessories and is not compatible with older Milton’s Bells electronic signaling kits.

Reliable Door Alerts for Demanding Workplaces

Designed for durability, flexibility, and everyday performance, the X5 Wired Warehouse Doorbell Kit is a dependable solution for businesses that need a hardwired doorbell button with the option to add louder alerts, visual signals, and additional wireless access points.

Whether you are covering a warehouse door, shop entrance, loading dock, or commercial workspace, the X5 Wired Warehouse Doorbell Kit helps keep your team connected and aware when someone needs attention.
